Features
|
Unit
|
SH-T6
|
SH-T7
|
SH-T10
|
SH-T20
|
|
Worktable Size(Length×Width)
|
mm
|
700*420
|
800*420
|
1100*500
|
1700*600
|
|
Travel X-axis
|
mm
|
600
|
700
|
1000
|
2000
|
|
Travel Y-axis
|
mm
|
400
|
420
|
500
|
600
|
|
Travel Z-axis
|
mm
|
300
|
300
|
330
|
600
|
|
Spindle Center to Column End
|
mm
|
464
|
464
|
546
|
660
|
|
Spindle Nose to Worktable Surface
|
mm
|
150-450
|
150-450
|
150-480
|
120-720
|
|
T-Slot (Quan./Size/Spacing)
|
mm
|
3-14-125
|
3-14-125
|
5-18-100
|
5-18-100
|
|
Spindle Taper(Model/Size)
|
-
|
BT30/φ100
|
BT30/φ100
|
BT30/φ100
|
BT30/φ120
|
|
Spindle RPM
|
rpm/min
|
20000
|
20000
|
20000
|
20000
|
|
Main Motor Power
|
kw
|
5.5
|
5.5
|
5.5
|
5.5
|
|
Fast Feed Speed (X/Y/Z)
|
m/min
|
48-48-48
|
48-48-48
|
48-48-48
|
48-48-48
|
|
Motor Connection Way (X/Y/Z)
|
-
|
Direct
|
Direct
|
Direct
|
Direct
|
|
Worktable Load Capacity
|
kg
|
300
|
300
|
350
|
650
|
|
Gross Weight
|
T
|
3.5
|
3.8
|
4.8
|
5
|
